750mm Vitrified Bond Grinding Wheel
Product Description
OD 750 mm grinding wheel is designed for heavy-duty industrial grinding applications requiring stable performance and dimensional accuracy.
Manufactured with selected abrasives and vitrified bond, this large-diameter grinding wheel offers excellent form holding, consistent cutting behavior and long service life.
The wheel is suitable for surface and cylindrical grinding operations,
where large diameter and stable structure are required. Custom specifications are available upon request.
Specifications
Wheel Shape: Straight wheel (Type 1)
Grit Size: 36#, 46#, 60#, 80#, 100# (customizable)
Abrasive: A/ PA/ SG/ WA/ WAA/ C
Hardness: J – P (customizable)
Bond: Vitrified (V)
Application Machine: Surface grinding machines
Specifications can be customized according to your grinding requirements.
|
Diameter (mm) |
Hole(mm) | Thickness(mm) | Abrasive | Grit |
Bond |
| 250 | 32 | 25/35 | A/ WA/ PA/ SA/ SG/ C/ GC/ Mixed | 36# / 46# / 60# / 80# / 100# / 120# | Vitrified Resined |
| 300 | 75/76.2/127 | 32/40/50 | |||
| 350 | 75/76.2/127/203 | 32/40/50 | |||
| 400 | 127/160/203 | 32/40/50/63 | |||
| 450 | 203/254/305 | 32/40/50/63/75 | |||
| 500 | 305 | 32/40/50/63/75/100 | |||
| 600 | 305 | 32/40/50/63/75/100/125 | |||
| 650 | 305 | 33/40 | |||
| 750 | 305 | 22/25/28/33/40/43/58/61/67/86 | |||
| 900 | 305 | 22/25/28/32/33/38/40/42/43/47/52/55/58/61/72/75/78/82/90 | |||
| 1065 | 304.8 | 22/25/32/38/42/47/52/55 | |||
| 1100 | 305 | 25/32/33/38/40/43/55/58/61/72/75/82/86/90 | |||
| 1200 | 305 | 120/150 | |||
| 1250 | 305 | 42/75/80 | |||
| 1400 | 305 | 80/86/120 | |||
| 1600 | 305 | 80/86/120 | |||
| 1600 | 900 | 86/90/120 | |||
| 1800 | 305 | 90/120 |
Applications
1. Surface grinding of carbon steel & alloy steel.
2. Grinding of tool steel and hardened steel (after heat treatment).
3. Precision grinding for dies, molds, plates, and mechanical components.
4. General surface grinding in machine shops and workshops.
5. Cylinder liners, crankshafts and camshafts grinding.
6. Auto parts, shipbuilding, engine repair workshop.
7. Rough grinding with high material removal.
Packaging & Delivery
Strong export-standard carton and pallet.
OEM label and private branding available
Stable supply for bulk orders
Product Advantages
- Specifically engineered for grinding crankshaft journals and pins with high roundness accuracy and stable profile control.
- Ensures excellent shape retention, thermal stability, and minimal deformation during heavy-duty grinding.
- Delivers smooth grinding performance with reduced chatter, improving surface finish and dimensional consistency.
- Strong self-sharpening ability enables fast material removal while maintaining long wheel life.
- Designed for long production cycles in crankshaft manufacturing and reconditioning workshops.
FAQ
Q1: Do you have experience in international grinding wheel business?
A: Yes. As a professional grinding wheel manufacturer, we have many years of experience in international business. Our vitrified grinding wheels have been exported to multiple countries and regions worldwide. Moreover, we maintain long-term cooperation with overseas customers in various industrial grinding applications.
Q2: How can I choose the right grinding wheel for my application?
A: To choose the right grinding wheel, you can first provide details such as the workpiece material, grinding process, and machine type. Based on this information, our technical team will recommend a suitable industrial grinding wheel. In addition, if you already have drawings or specifications, we can produce customized grinding wheels according to your requirements.
Q3: How do you ensure the quality of vitrified grinding wheels?
A: All vitrified grinding wheels are manufactured under strictly controlled production processes. Before shipment, each grinding wheel is inspected to ensure stable performance, accurate dimensions, and consistent quality. As a result, our products are reliable for long-term industrial grinding operations.
Q4: Do you offer customized grinding wheel solutions?
A: Yes. As an experienced grinding wheel supplier, we offer customized grinding wheels with different sizes, bores, abrasive types, and grit specifications. Therefore, we can provide grinding wheel solutions tailored to various industries and applications.
Q5: What after-sales service do you provide for grinding wheels?
A: If any quality-related issues occur with our grinding wheels, please contact us with detailed application feedback. After analyzing the grinding conditions, our technical team will provide professional technical support or suitable solutions to ensure smooth and efficient grinding performance.
